Sefa has been for more than 40 years, a French designer and manufacturer of fully programmable automation large format hot transfer presses for the textile industry and the sublimation market on solid materials to receive ChromaLuxe approved status.
The pneumatic SLIDE 865 was created for high-quality rigid substrates for sublimation printing on Sublimation Rigid Substrate, Textile Sublimation Useful size 80x60 cm up to The Power supply is 240 V Single-phase (Neutral + Ground) and 400 V 3-phases (Neutral + Ground)
Operation Slide - Tray with drawer
Platen size 85x65 cm / 33x26 "
Max thickness 45 mm
Weight 261 Kg / 575 lbs
Pressure 453 gr/cm²
°C / °F Max 220 °C / 429 °F
Power 6000 W
Power supply 240 V Single-phase + Neutral + Ground, 400 V 3-phases + Neutral + Ground
Amperage 28 A, 9 A
Dimension 794x1756x893 mm / 31x69x35 "
The pneumatic SLIDE 1285’s two independent heating areas give you the power to sublimate very high-definition images up to useful size 120 x 80 cm onto a range of substrates, including textiles, aluminium, MDF, wood, tiles, etc. The Power supply is 400 V 3-phases ( Neutral + Ground)
Operation Slide - Tray with drawer
Platen size 125x85 cm / 49x33 "
Max thickness 45 mm
Weight 419 Kg / 924 lbs
Pressure 386 gr/cm²
°C / °F Max 220 °C / 429 °F
Power 12000 W
Amperage 18 A
Dimension 794x2153x1286 mm / 31x85x50 "
